2902 Walkaround • Owner’s Manual Supplement Chapter 12: Electrical System
Electrical Routings
Deck Electrical Harness
ALL AROUND LIGHT
COURTESY LIGHTS
COURTESY LIGHTS
SPEAKER
12 VOLT RECEPTACLE
STEREO
LIGHT SWITCH
MAX SWITCH
COURTESY LIGHT
REFRIGERATOR
GALLEY LIGHTS
WIPER
SPEAKERS
BOW LIGHT
HORN
CABIN LIGHTS
WIPER (IF EQUIPPED)
CARBON MONOXIDE DETECTOR
CABIN LIGHT
HEAD LIGHTS
SPEAKER
NOTE: VIEW IS UNDERSIDE OF DECK
DASH HARNESS
SHIFTER
