2902 Walkaround • Owner’s Manual Supplement Chapter 2: Locations
Component Locations
12-Volt Accessory Outlet: Located at the
helm on the switch panel.
Air Conditioner Seawater Intake
Seacock: Located in the cockpit access hatch.
Air Conditioner Unit (If Equipped):
Located under the helm seat. Access is
through the storage hatch below the helm seat.
12 VOLT
RECEPTACLE
COCKPIT ACCESS
HATCH
STORAGE
HATCH
