2902 Walkaround • Owner’s Manual Supplement Chapter 2: Locations
Aft Bilge Pump & Float Switch: Located in
the aft bilge. Access is through the large hatch
in the aft cockpit.
Forward Bilge Pump:
• Located under the cuddy cabin
entry floor.
• Access is through the floor plate.
Carbon Monoxide Detector: Located on
the aft starboard wall of the cuddy cabin.
AFT BILGE ACCESS
THROUGH THIS HATCH
FLOOR PLATE
HEAD DOOR
CO MONITOR
