Trotec IDE 20 User Manual

EN 19
oil heater IDE 20 / IDE 30 / IDE 50 / IDE 60 / IDE 80
Technical annex
Technical data
Parameter Value
Model IDE 20 IDE 30 IDE 50 IDE 60 IDE 80
Combustion indirect indirect indirect indirect indirect
Air volume 600 m³/h 780 m³/h 2000 m³/h 2000 m³/h 2000 m³/h
Fan axial fan axial fan axial fan axial fan axial fan
Nominal heat output 20 kW 30 kW 50 kW 60 kW 80 kW
Power consumption 230 W 230 W 900W 900W 900W
Operating temperature -20 °C to +45 °C -20 °C to +45 °C -20 °C to +45 °C -20 °C to +45 °C -20 °C to +45 °C
Relative humidity during
operation
max. 80 % RH max. 80 % RH max. 80 % RH max. 80 % RH max. 80 % RH
Temperature increase ΔT 90 °C 95 °C 95 °C 90 °C 105 °C
Max. fuel consumption 1.9 l/h 2.8 l/h 4.8 l/h 5.7 l/h 7.6 l/h
Tank capacity 24 l 50 l 69 l 69 l 69 l
Flue pipe connection Ø 120 120 150 150 150
Input voltage 230V/ 50Hz 230V/ 50Hz 230V/ 50Hz 230V/ 50Hz 230V/ 50Hz
Current consumption 1.1 A 1.5 A 3.2 A 3.2 A 3.3 A
Overheating protection yes yes yes yes yes
Connection for external
thermostat
yes yes yes yes yes
Sound pressure level
(distance 1m)
79 dB(A) 78 dB(A) 79 dB(A) 79 dB(A) 80 dB(A)
Weight (with empty tank) 22.5 kg 34.5 kg 59 kg 59 kg 59 kg
Dimensions (length x
width x height)
840x 450x
695 mm
1107x 498x
766 mm
1365x 550x
985 mm
1370x 560x
995 mm
1370x 560x
995 mm
Minimum distance to walls
or other objects
top
rear
sides
front
2 m
2 m
3 m
3 m
2 m
2 m
3 m
3 m
2 m
2 m
3 m
3 m
2 m
2 m
3 m
3 m
2 m
2 m
3 m
3 m
Permitted fuel EL fuel oil, diesel
or kerosene
EL fuel oil, diesel
or kerosene
EL fuel oil, diesel
or kerosene
EL fuel oil, diesel
or kerosene
EL fuel oil, diesel
or kerosene
Wear hearing protection.
Excessive noise can lead to hearing loss.
