oil heater IDE 20 / IDE 30 / IDE 50 / IDE 60 / IDE 80
Spare parts list IDE 20
NO. SPARE PART NO. SPARE PART NO. SPARE PART
1 Oil drain seel Ring 24 Power PCB 47 Fan
2 Oil drain screw 25 Bottom casing 48 Top cover
3 Fuel tank 26 Heat insulation casing 49 Chimney connector
4 Support 27 Chamber bracket 50 Side plate
5 Power cord 28 Combustion chamber 51 Wheel axle
6 Cable fastener 29 Hook 52 Feet pipe
7 Ignition transformer 30 Air inlet disc 53 Cotter pin
8 Bracket Of Ignition transformer 31 Photocell assembly bracket 54 Wheel
9 Fuel filter 32 Photocell assembly 55 Flat gasket
10 Sealing ring 33 Re-set thermostat bracket 56 Screw nut
11 Brealth cover 34 Re-set thermostat 57 Steel pipe plug
12 Fuel tank cap 35 Flame plate 58 Handle
13 Sealing ring 36 Nozzle assembly A-1 Socket
14 Tank cap shaft 37 Nozzle Adapter A-2 Buckle
15 Oil inlet filter holder 38 Gas hose A-3 Socket cap
16 Oil inlet filter 39 Oil hose A-4 Plug
17 Oil leveler 40 Ignition needle A-5 Line
18 Capillary thermostat 41 High voltage cable A-6 Knob
19 Thermostat knob 42 Solenoid valve A-7 Top cover
20 Light cover 43 Solenoid valve bracket A-8 Capillary thermostat
21 On/off Switch 44 Air inlet grill A-9 Bottom cover
22 Control panel 45 Motor support
23 PCB bracket 46 Motor assembly
