Safety
The machine is equipped with following safety devices:
No. Description No. Description
1 Main switch 5 Interlock safety switch
2 Emergency stop button (only with temperature
sensor option)
6 Side panel right (with interlock safety switch)
3 Temperature sensor reset button (only with
temperature sensor option)
7 Side panel left (with interlock safety switch)
4 Key switch 8 Acrylic top lid
2.7 Technical protective measures
2.7.1 Main switch
Pressing the main switch on the backside of the machine to disconnect the machine from the mains power
supply.
2.7.2 Key switch
Turning the key switch counterclockwise powers off the motor, laser source and electric system. Through the
key switch, operation by non-authorized personnel can be prevented.
22
