Operation
7.7.3 Software focus
The following values must be entered in JobControl®:
•
Table type
•
Lens type
•
Material thickness (exact measurement)
•
Material process type
Caution
The values entered must match the material, table and lens in the machine in order to avoid a
head crash.
When using spacer the total material thickness is determined by the thickness of the spacer and
the material.
1. Click on the icon "Options" or go to Settings/
Options in the menu.
2. Select "Accessories".
3. When you are using a cutting table enter the
table type and the thickness of the table.
4. Select the lens type in the menu bar.
5. Click on the icon "Material database" or got
to Settings/Material database in the menu .
6. Enter the material thickness.
7. Enter the process type.
8. Click on the icon "Focus laser". The working
table moves automatically to the correct
position (moves in Z direction).
73
