Trotec Speedy 360 User Manual

Setup and installation
6 Setup and installation
6.1 For your safety
Notice
The setup has to be carried out by Technical Support.
6.2 Temperature and humidity
Ambiente conditions
Operating temperature (ambiente temperature): +15 °C to +25 °C
Relative humidity: 45-65%, non-condensing
•
If the system has been exposed to large temperature fluctuations, it must first be brought back to room
temperature before commissioning.
Environmental conditions
•
Provide sufficient illumination at the workplace.
•
Ensure a dust-free environment (II° according to IEC60947-1).
•
Shielding from EMC.
•
Freedom of interfering electrical installations, hoses and pipe lines.
•
Power supply free of fluctuations.
53

Trotec Speedy 360 Specifications

General

Max. Speed	3.55 m/s
Laser Type	CO2 Laser
Software	JobControl
Resolution	1, 000 dpi
Positioning Accuracy	0.1 mm
Repeatability	± 0.01 mm
Power Supply	110 - 240 V, 50/60 Hz
Weight	220 kg
Laser Power	10 - 120 watts
