Model 3411-B Advanced Control Unit 2–17
2. GAUGE OPERATION
M Count: xxx
D Count: xxx
WD: xxx.x PCF
% MA xx.x %
DD: xxx.x PCF
(Use ↑ & ↓ keys)
Moist: xxx.x PCF
% Moist: x.x %
% Voids: xx.x %
100-%MA: xx.x %
MOIST CR: x.xxx
DENS. CR: x.xxx
where:
WD = Wet density in kg/m
3
or pcf
% MA = Percent Marshall (This value is valid only if an
appropriate target has been entered for the material
being tested.)
DD = Dry density in kg/m
3
or pcf
MOIST = Moisture value in kg/m
3
or pcf
% MOIST = Percent moisture
% VOIDS = 100 (1 – WD/VOIDLESS)
100 – % MA = Value given by subtracting the percent
Marshall value from 100
MOIST CR = Moisture count ratio
DENS. CR = Density count ratio
M Count = Moisture counts as read by the gauge
D Count = Density counts as read by the gauge
Press 〈ON/YES〉 to return to the Ready mode.
