REPLACEMENT PARTS
Figure B–1 shows the replaceable parts of the Model 3411-B
Advanced Control Unit.
Match the reference number (Ref #) shown below with the correct
part in Figure B–1.
Ref # Part Number Description Qty
1 000001.0400 #4 Internal Lock Washer 4
2 000204.1400 4-40 Pan Head Screw, Phillips 4
3 001061.0820 4-40 Hex Spacer, MF 4
4 002516 Jack Cover Assembly 1
5 100528.1000 Captive Thumb Screw, 8-32 4
6 102888 Cable Assembly 1
7 110237 (Bottom) Printed Circuit Board Assembly 1
8 110237 (Top) Printed Circuit Board Assembly 1
9 110240 Operator Overlay 1
10 110241 Front Panel Assembly 1
11 110245 Charger Jack Assembly 1
12 110248 Cable Assembly 1
13 110254 Cable Assembly, Backlight 1
Appendix B–8
