Ref.
No.
Part No. Description
126 715-04088 Dowel Pin
127 951-10645A Electric Starter
128 710-04979 Bolt
129 9 51-1110 9 Blower Housing Shield
130 951-10639A Primer
131 710-04945 Bolt
132 710-04938 Drain Bolt
143 731-05696 Starter Handle
155 9 51-1110 6 Governor Arm Bracket
156 951-11903 O-Ring
157 9 51-116 8 0 Wire Clip
— 951-10651 Fuel Tank Nipple (Not Shown)
— 952Z270-SU Engine, Complete
33 951-10638A Carburetor Assembly
130 951-10639A Primer
131 710-04945 Bolt
132 710-04938 Drain Bolt
133 — Gasket, Throttle Plate
134 — Float Pin
135 — Emulsion Tube
136 — Needle Valve
137 — Main Jet
138 — Needle Valve Spring
139 — Float
140 951-11589 Fuel Bowl Gasket
141 9 51-113 49 Fuel Drain Plug Gasket
142 9 51 -113 4 8 Fuel Bowl Gasket
146 — Choke Shaft
147 — Choke Plate
148 — Throttle Shaft
149 — Throttle Plate
150 — Screw, M3×5
151 — Lock Washer
152 — Idle Jet Assembly
153 — Idle Speed Adjusting Screw
154 — Fuel Bowl
158 751-11906 Hose Clamp
159 751-12006 Primer Hose
Ref.
No.
Part No. Description
— 951-110 6 0A Short Block Assembly (Not Shown)
5 951-115 65 Head Cover Gasket
21 9 51-112 89 Muer Gasket
30 9 51-115 67 Carburetor Insulator Gasket
31 751-1189 6 Carburetor Insulator Plate
46 951-115 72 Cylinder Head Gasket
48 751-118 9 9 Tappet
49 715- 04090 Dowel Pin
52 951-112 53 Piston Ring Set
53 951-11632 Piston Pin Snap Ring
54 751-12007 Piston
55 9 51-11633 Piston Pin
58 9 51-115 73 Connecting Rod Assembly
59 9 51-113 56 Governor Arm Shaft
60 736-04461 Washer
61 751-11902 Governor Seal
62 714-04074 Cotter Pin
63 9 51-11575 Camshaft Assembly
64 951-113 69 Radial Ball Bearing
65 951-10307 Flywheel Key
66 — Crankshaft Assembly
67 9 51-115 76 Governor Gear/Shaft Assembly
68 715- 04092 Dowel Pin, 7 x 14
69 715- 04096 Dowel Pin, 9 x 14
70 951-11371 Crankcase Cover Gasket
71 — Case Cover
72 710-04932 Bolt
73 9 51-1157 7 O-Ring
74 — Oil Fill Plug
75 9 51-113 6 8 Oil Seal
76 — Crankcase
77 9 51-113 50 Oil Drain Pipe
78 736-04440 Washer
79 710-04906 Oil Drain Plug
80 9 51-1137 0 Oil Seal
145 951-10657 Muer Stud Assembly
20 710-05001 Stud
14
208 cc 270-SU Engine
