Shroud, Chute, & Handle
Ref.
Part Number Description
1. 731-06551 Shroud
684-04236A† Shroud
2. 710-04669 Hex Washer Screw, 10-16 x .625
3. 710 -1205 Eye Bolt, ⁄-20
4. 720-0279 Knob Handle
5. 710-0895 Hex Washer Screw, ⁄-15 x .750
6. 712- 04063 Flange Lock Nut, ⁄-18
7. 710 -1090 Hex Screw, ⁄-18 x 1.25
8. 931-04353 Lower Chute Ring
9. 932- 0 4111 Chute Adjustment Spring
10. 931-04886 Chute Adapter
11. 931-04127 Lower Chute, 5” Diameter
12. 731-04426A Upper Chute
13. 720-04072A Wing Knob
14. 731-04388A Chute Handle
15. 710-0451 Carriage Bolt, ⁄-18 x .750
16. 710-04071 Carriage Bolt, ⁄-18 x 1.00
17. 725-0157 Cable Tie, ⁄ x .05 x 7.4
18. 74 9 - 0 4114 B Lower Handle
19. 710-04532 Carriage Screw, ⁄-18 x 2.00
20. 749-04106A Gullwing Handle
21. 747- 04159A Gullwing Control Bail
22. 731-1033 Shave Plate, 21”
23. 712-04064 Flange Lock Nut, ⁄-20
24. 710-0134 Carriage Screw, ⁄-20 x .62
25. 710-3008 Hex Screw, ⁄-18 x .75
26. 936-0176 Flat Washer, .265 x .938 x .120
27. 746-04237 Clutch Cable
28. 710-1882† Hex Screw, ⁄-18 x 1.50
† Model 2M5
