Drive System & Auger Assembly
Ref.
Part Number Description
1. 734-04033 Wheel, 8 x 2 (Gray)
734-04063A† Wheel, 7 x 1.5 (Gray)
2. 936-0326 Flat Washer, .510 x 1.000 x .125
3. 710-0599 Hex Screw, ⁄-14 x .500
4. 710-1044 Hex Screw, ⁄-24 x 1.50
710-0627† Hex Bolt, ⁄-24 x .75
5. 736-0247 Flat Washer, .406 x 1.25 x .157
736-0371† Bell Washer, .343 x .880 x .062
6. 756-04353 Pulley Half, 4L-V x 2.30 OD
956-0416B† Pulley Half, .625 ID x .225 OD
7. 954-04204 V-Belt
954-0101A† V-Belt
8.
750-04303††
Spacer, .875 ID x 1.185 OD
9.
750-05084††
Spacer, .88 ID x 1.18 OD x .74 Lg.
10. 756-04232 V-Type Pulley, ⁄ x 35.7
11. 710-0409 Hex Screw, ⁄-24 x 1.75
12. 93 6 - 0119 Lock Washer, ⁄
13. 926-0154 Cable Tie, 7.5
14. 790-00334 Engine Support Bracket
790-00216† Engine Bracket
15. 710-0623 Hex Washer Screw, ⁄-16 x .50
16. 750-04297B Spacer, .875 x .320 x 1.027
17. 710-0896 Hex Washer Screw, ⁄-14 x .625
18. 710-0653 Hex Washer Screw, ⁄-20 x .375
19. 790-00045C Belt Cover
684-04357† Belt Cover
20. 710-0106 Hex Screw, ⁄-20 x 1.25
21. 750-04571 Shoulder Spacer, .260 x .785 x .538
22. 684-04168 Pulley Assembly, 1.917 OD
23. 712-04063 Flange Lock Nut, ⁄-18
24. 748-0234 Shoulder Spacer
Ref.
Part Number Description
25. 790-00238A Idler Bracket w/ Brake
26. 712-04064 Flange Lock Nut, ⁄-20
27. 790-00249 Bearing Cup
28. 741- 04188A Ball Bearing, 1.25 x 37 x 12.6301
29. 710-0642 Hex Screw, ⁄-20 x .750
30. 936-0329 Lock Washer, ⁄
31. 738-0924A Shoulder Screw, .340 x .335 x ⁄-28
32. 756-0625 Cable Roller
33. 936- 0176 Flat Washer, .265 x .938 x .120
34. 712-0896 Hex Lock Nut, ⁄-28
35. 932-0357A Extension Spring, .33 OD x 1.12
36. 684-04252 Auger Assembly, 21”
684-04227† Auger Assembly, 21”
37. 710-05058 Hex Screw, ⁄-14 x .75
38. 735-04033 Rubber Pad
39. 735-04032 Spiral Crescent
40. 750-04758 RH Spacer
41. 750-04757 LH Spacer
42. 726-0299 Push Cap, ⁄
43. 684-04314 Auger Housing
44. 710 -0751† Hex Bolt, ⁄-20 x .620
45. 712-04064† Flange Lock Nut, ⁄-20
46. 726-0205† Hose Clamp, .490
47. 726-0233† Push Nut, .25 ID x .50 OD
48. 747-04236† Fuel Tank Support Wire
49. 951-10023† Fuel Tank, 2 Qt.
50. 751-10487† Fuel Cap
51. 790 -00134† Fuel Tank Bracket
52. 751-10349† Fuel Line Hose
NS
929-0071A^††
Extension Cord
† Model 2M5
†† Model 2P5
^ Not Shown
