Troy-Bilt Squall 2100 - Page 9

Ref.
No.
Part No. Description
1 710-04920 Flange Bolt
8 715-04092 Dowel Pin, 7 x 14
12 714-04074 Governor Arm Clip
16 710-04906 Drain Plug Bolt
17 736-04440 Drain Plug Washer
18 951-10958 Ignition Coil
19 9 51-1110 2 Flywheel Bae
20 710-04919 Flange Bolt
21 951-10908 Flywheel
22 951-10910 Cooling Fan
23 951-10 911 Starter Cup
24 712- 04209 Nut
25 951-1110 7 Blower Housing
26 710-04914 Flange Bolt
28 731-05696 Recoil Starter Handle
29 712 - 0 4211 Nut
30 951-1110 6 Governor Arm Bracket
31 710-04908 Bolt
32 951-10954 Throttle Return Spring
33 951-11152 Governor Rod
34 951-10953 Governor Return Spring
36 9 51-1110 3 Cover Shield
37 9 51-1110 4 Governor Spring Bracket
38 710-04921 Flange Bolt
39 951-10901 Muer Assembly
41 712-04212 Nut
42 951-10962 Intake Heater Box Base
43 951-10961 Intake Heater Box
44 710 -04913 Bolt
46 951-10639 Primer
47 951-10956 Carburetor Assembly
50 710-04902 Pivot Bolt
52 751-1112 3 Valve Adjusting Nut
53 751-11124 Pivot Locking Nut
61 951-10913 Push Rod Kit
68 710-04916 Bolt
69 951-110 54 A Valve Cover
71 710-04922 Bolt
72 731-07059 Breather Hose
73 951-10292 Spark Plug
Ref.
No.
Part No. Description
75 951-10657 Muer Stud Assembly
77 715- 04090 Dowel Pin, 10 x 16
78 710-04909 Carburetor Studs
80 715-04089 Dowel Pin, 9 x 14
82 726-04101 Hose Clamp
83 710-04916 Bolt
85 951-1110 5 Cylinder Bae
87 712-04210 Nut
88 710-04918 Flange Bolt
90 951-10959 Muer Gasket
91 951-10955 Recoil Starter Assembly
92 951-10307 Flywheel Key
96 951-10957 Dipstick Assembly
108 951-10912 Valve Kit
110 710-04928 Bolt
NS 731-05632 Ignition Key
— 951-11095 Crankcase Cover Kit
4 — Crankcase Cover
9 — Case Cover Gasket
96 951-10957 Dipstick Assembly
— 951-10951A Gasket Kit - Complete
5 — Oil Seal
9 — Crankcase Cover Gasket
11 — O-ring, 5.2 x 1.9
45 — Carburetor Gasket
70 — Head Cover Gasket
76 — Cylinder Head Gasket
79 — Carburetor Insulator Gasket
81 — Packing
84 — Oil Seal, 22 x 35 x 7
90 951-10959 Muer Gasket
95 951-10370 Oil Drain Plug and Washer Assembly
96 951-10957 Dipstick Assembly
— 951-10952A Gasket Kit - External
70 — Head Cover Gasket
79 — Carburetor Insulator Gasket
81 — Packing
90 951-10959 Muer Gasket
95 951-10370 Oil Drain Plug and Washer Assembly
96 951-10957 Dipstick Assembly
9
123cc 161-JWA Engine
