CHAPTER 2: ASSEMBLY GUIDE
14 of 50
ASSEMBLY STEPS:
Step 1 Pedestal Wire Connections:
Step 2 Pedestal Uprights:
a) Connect the network & coaxial wires
coming from the bottom of the le
pedestal to the corresponding cables
coming from the base of the machine.
b) Connect the data & power cables
coming from the bottom of the right
pedestal to the corresponding cables
coming from the base of the machine
a) Install each Pedestal Upright as
shown.
*DO NOT pinch cables.
b) Secure the each pedestal upright with
4 bolts and 4 washers, but do not fully
tighten.
Hardware Required:
8 M10xP1.5x20mm Bolts
8 M10 Lock Washers
