Z8.1e Elliptical Owner’s Guide
More Data Readouts
TEST MODE
126
Ext SRAM: Confirms static RAM system is operating. Example
value: PASS.
PWM Drive: Actual pulse width modulation value. When
cursor is under PWM target, should be close to or match PWM
Target. Example value: 12157.
Load Target: Not used.
Load Sense: Current in amperes from the electromagnetic
brake load coil. Example value: 0.85.
Load ON/OFF: Enables or disables LCB load feedback control.
Should always be ON. If OFF, the LCB will ignore the PWM
drive signal and remove the load current feedback. Example
value: ON.
Keypress: Pressing each key will play a tone and identify the
key on the display.
Stride Control: manual control of stride length adjustment
using the and keys.
Stride Position: relative stride position using motor
dimensions, not actual stride length.
TEST MODE
