Data Readouts (cont.)
TEST MODE
Z8.1e Elliptical Owner’s Guide
127
Stride: Not used on ellipticals.
C-Pump: Unregulated voltage from charge pump circuit for
contrast control. Example value: 30.11.
S-Caps: Voltage level of super capacitors, which provide power
for the elliptical during workout pause. About 45 seconds of
pedaling should result in a full charge of 4.82 volts. Example
value: 4.82.
Contrast: Regulated voltage for contrast control. Example
value: 24.50.
Watts: Actual watts as measured from the electromagnetic
brake. Example value: 125.
Targ PWR: The adjusted power requested of the
electromagnetic brake. Will typically be the same as Prog PWR,
except when pedal RPM falls below 60, when torque roll-off
occurs. Example value: 110.
TEST MODE
Prog PWR:
Prog PWR: (editable): The power requested by the user or
workout program. Example value: 130.
Stride Cal:
Stride Cal: Calibrate the stride adjust system. Perform this
procedure during installation and following any servicing:
Press until the cursor is on Stride Cal. Press
to start calibration.
Wait for the stride length to adjust up and down,
then Stride Cal should display GOOD.
Press and hold to get back to normal operation
mode.
