Truma CP plus Operating And Installation Instructions

8
Enter the end time
• Use the rotary push button(8) to set the
hours and then the minutes.
24h mode 12h mode
hot
= a. m.
= p. m.
hot
If the start/end time is later than the time
when you entered the settings, the operat-
ing parameters are not active until the next
start/end time is reached. Until then, the
operating parameters set outside the time
switch remain valid.
Set the room temperature
• Select the desired room temperature with
the rotary push button(8).
• Tap the rotary push button(8) to confirm the
value.
hot
F
Example: Temperature display in °F
Set the hot water level
• Select the desired hot water level with the
rotary push button(8).
• Tap the rotary push button(8) to confirm the
value.
hot
Select energy mode
• Select the desired energy mode with the ro-
tary push button(8).
• Tap the rotary push button(8) to confirm the
value.
hot
The “Select energy mode” menu is dis-
played only if a furnace with electric heat-
ing elements is connected
(Truma Combi eco plus or
Truma Combi comfort plus).
Select fan speed
• Select the desired fan speed with the rotary
push button(8).
• Tap the rotary push button(8) to confirm the
value.
hot
The “Select fan speed” menu is displayed
only if the room temperature was set.
Enable the time switch (ON)
• Enable the time switch (ON) with the rotary
push button(8)
• Tap the rotary push button(8) to confirm the
value.
hot
2
The time switch remains enabled, even for
several days, until it is disabled (OFF). If the
time switch is programmed and enabled,
the time switch icon is shown in the status
line(2). If the time switch is active, the icon
flashes.

Truma CP plus Specifications

General

Display	LCD
Power supply	12 V DC
Quiescent current consumption (at 12 V)	Approx. 5 mA
Temperature range	-15 °C to +60 °C
Protection class	IP20
Compatibility	Truma Combi heaters
