Truma CP plus Operating And Installation Instructions

9
Disable the time switch (OFF)
• Tap the rotary push button to go to the set-
ting level.
• Disable the time switch (OFF) with the rotary
push button(8)
• Tap the rotary push button(8) to confirm the
value.
hot
Set clock
Display 24h mode Display 12h mode
hot
4
hot
4
= a. m.
= p. m.
• Use the rotary push button(8) to select the
“Set clock” icon in the menu line(4).
The hour display flashes.
• Use the rotary push button(8) to set the
hour.
• Tap the rotary push button(8) again and the
minute display flashes.
• Use the rotary push button(8) to set the
minutes.
• Tap the rotary push button(8) to confirm the
value.
Settings
• Use the rotary push button(8) to select the
“Settings” icon in the menu line(4).
• Tap the button to go to the setting level.
1. Show version number of connected
devices
Display the version number of furnace and
control panel.
hot
2. Backlighting
Change the backlighting of the CP plus control
panel in 10increments.
hot
3. Language
Select the desired language (English, German,
French, Italian).
hot
4. 12h / 24h Mode
Display in 12h (a. m., p. m.) / 24h mode.
hot
Default 12h mode.

Truma CP plus Specifications

General

Display	LCD
Power supply	12 V DC
Quiescent current consumption (at 12 V)	Approx. 5 mA
Temperature range	-15 °C to +60 °C
Protection class	IP20
Compatibility	Truma Combi heaters
