3
Installation Instructions
Safety instructions
In-vehicle installations must comply with
the technical and administrative regula-
tions of the respective country of use (e.g.
EN 1648, VDE 0100-721). National regula-
tions and rules must be followed.
In other countries, the relevant regulations
must be observed.
Intended use
The iNet Box was developed for controlling TIN-bus-capable
Truma devices via mobile terminal devices (e.g. smartphones,
tablet PCs). Communication is via Bluetooth or GSM.
Scope of delivery
1 iNet Box
1 Fastening bracket
1 Set of operating instructions
1 Set of installation instructions
1 12 V connector cable 30 cm (+ = red ,
-
= blue)
1 Connector cable (TIN-bus)
Accessories
External GSM antenna
TIN-bus cable, 3 different lengths
Dimensions
L x W x H 147 x 96 x 40
The dimensions are in mm
Connections
Front view
POWER (9 V – 29 V operating voltage)
TIN 1
TIN 2
