3
Operating Instructions
Safety instructions
– iNet Box must not be operated unless it is in technically per-
fect condition.
– Repairs must be carried out immediately. Only carry out
repairs yourself if the solution is described in the trouble-
shooting guide of this manual.
– A defective iNet Box may only be repaired by the manufac-
turer or the manufacturer’s service department.
– Do not perform any modifications to the iNet Box as this
can be dangerous.
– Changes or modifications not expressly approved by the
party responsible for compliance could void the user’s
authority to operate the equipment.
– This device complies with Part 15 of the FCC Rules and with
Industry Canada license-exempt RSS standard(s). Operation
is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired
operation.
– Le présent appareil est conforme aux CNR d‘Industrie
Canada applicables aux appareils radio exempts de licence.
L‘exploitation est autorisée aux deux conditions suivantes :
(1) l‘appareil ne doit pas produire de brouillage, et
(2) l‘utilisateur de l‘appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est suscepti-
ble d‘en compromettre le fonctionnement.
Display and control panels / connections
Display panels
BLUETOOTH
POWER
GSM
iNet Box
Figure 1 – Top view
LED Description
Blue Bluetooth – flashes for Bluetooth pairing with 1Hz
Green Power – lights up when ready for operation
Red GMS – lights up when GSM operation is not possible
Control panels / connections
SIM
GSM
EXT
INT
1
Figure 2 – Rear view
Item Description
1 Bluetooth / factory setting button
2 Insert, Mini-SIM card (25 x 15 mm)
3 External antenna connection GSM (SMA)
4 Changeover switch, internal / external antenna
To Next Page
