Leg section toothed belt
68 Service Manual MARS 2 1 435 274 - 09/07
30. Switch off the operating table (remote control).
31. Carefully insert the plug into the seat section strut.
32. Mount the cover (sheet metal guard) [4] and connect the cable shielding (2 machine
screws).
33. If necessary, attach new self-adhesive covering foils over the apertures in the seat
section strut.
34. Repeat work steps 31. to 33. on the other seat section strut.
35. Remount the plastic plate [2] on the seat section (4 ball-heads [3]).
36. Press the previously removed pad [1] onto the 4 ball-heads [3].
37. Mount the cover plate (4 countersunk screws).
38. Put the cover battery compartment on the running gear.
39. Connect the power supply, and switch the operating table on.
CAUTION
Risk of injury from the capacitor voltage.
All LEDs on the membrane keyboard must be out.
TEST
Check the operating table functions.
