When operating power tools outdoors, use a grounded extension cable labeled “For
Outdoors Use”. These extensions are especially designed for operating outdoors and reduce the risk of electric
shock.
3
SCI-10
Technical Data
Power Requirements
16277
Width: 1/4” - 1/2”
Length: 5.6’
Clase I
60 Hz
Band Saw
18 AWG x 3C with insulating temperature of 221°F
2788 ft/min
3.2 A / 1.7 A
1/3 HP
Code
Description
Cutting Band
Voltage
Frequency
Current
Power
Band Speed
Conductors
Insulating
60 minutes work and 30 minutes idle. Maximum 6 hours per day.
Duty cycle
Power Cord Grips used in this product: Type “Y”.
Tool Build Quality: Basic insulation
Thermal insulation on motor winding: Class B
/120 V
220 V
From 0 and up to 10 A
From 10 and up to 13 A
From 13 and up to 15 A
From 15 and up to 20 A
18 AWG
16 AWG
14 AWG
8 AWG
16 AWG
14 AWG
12 AWG
6 AWG
3 (one grounded)
Ampere
Capacity
Number of
Conductors
Extension Gauge
The tool shall be grounded while being used to prevent electric shock.
• Connect the plug into a properly grounded electric contact as shown in
example A. Not all contacts or plugs are properly grounded. In doubt please
verify with a qualified electrician.
• If the electric contact to be used with the tool has two poles (2 orifices), DO
NOT REMOVE OR ALTER THE GROUND CONDUCTOR IN THE PLUG. Use a
temporary adaptor as shown in example B, and always connect the ground
conducting lug as indicated.
When using an extension cord, verify the gauge is enough for
the power that your product needs. A lower gauge cable will cause voltage drop
in the line, resulting in power loss and overheating. The following table shows the
right size to use depending on cord´s length and the ampere capability shown in
the tool’s nameplate. When in doubt use the next higher gauge.
A
B
WARNING
CAUTION
WARNING
WARNING
Avoid the risk of electric shock or severe injury. When the power cable gets damaged
it should only be replaced by the manufacturer or at a Authorized Service Center.
The build quality of the electric insulation is altered if spills or liquid gets into the tool while in use.
Do not expose to rain, liquids and/or dampness.
Before gaining access to the terminals all power sources should be disconnected.
WARNING
CAUTION
from 5,9’ to 49,2’ | higher than 49,2’
ENGLISH
