TSC DA310 Series - Loading Media in Cutter Mode (Option for DA220 series)

- 14 -
4. Feed the media through the rear external
label entrance chute. (printing side face up)
Place the label leading edge onto the platen
roller.
5. Close the top cover gently and make sure the
cover latches securely.
6. Use “Diagnostic Tool” to set the media
sensor type and calibrate the selected
sensor. (Start the “Diagnostic tool”  Select
the “Printer Configuration” tab  Click the
“Calibrate Sensor” button)
Note:
* Please calibrate the gap/black mark sensor when changing media.
* Please refer to video on TSC YouTube or driver CD.
