TSC MB240 Series User Manual

- 27 -
4. Adjustment Knob
4.1 Print Head Pressure Adjustment Knob
The print head pressure adjustment knob has 6 levels of adjustment for 1~2" and 3~4" media widths.
Because the printer’s paper alignment is to the left side of mechanism, different media widths require the
different pressure to print the label correctly. Therefore, it may require adjusting pressure to get the best
print quality.
Print Head Pressure
Adjustment range from 1~2"
media width
Print Head Pressure
Adjustment range from
3~4" media width

TSC MB240 Series Specifications

General

Print Method	Thermal Transfer/Direct Thermal
Resolution	203 dpi
Processor	32-bit RISC CPU
Operating Humidity	25-85% non-condensing
Connectivity	USB 2.0, RS-232
Media Sensor	Reflective, Transmissive
Media Type	Continuous, Die-cut, Black mark, Fan-fold, Notched
Media Width	25.4 mm
Media Thickness	0.06 mm
Media Core Diameter	25.4 mm (1")
Media Max Roll Diameter	127 mm (5")
Ribbon Width	110 mm
Ribbon Length	300 m
Ribbon Core Diameter	25.4 mm (1 inch)
Power	100 - 240 VAC, 50/60 Hz
Maximum Print Length	9999 mm
Label Width	25.4 mm
Label Thickness	0.06 mm
Power Supply	100-240V AC, 50-60Hz
Operating Temperature	5°C - 40°C
Storage Temperature	-20°C - 60°C
Certifications	CE
