TSC MB240 Series User Manual

- 47 -
6.5.3 Wi-Fi
This option is used to set the printer Wi-Fi settings.
Item
Description
Default
Status
Use this menu to check the Wi-Fi IP address, MAC
setting status….
N/A
Config.
DHCP:
This item is used to ON or OFF the DHCP (Dynamic
Host Configuration Protocol) network protocol.
Static IP:
Use this menu to set the printer’s IP address, subnet
mask and gateway.
DHCP
SSID
Use this menu to set the Wi-Fi SSID
N/A
Security
Use this menu to set the Wi-Fi security
Open
Password
Use this menu to set the Wi-Fi password
N/A
6.5.4 Bluetooth
This option is used to set the printer Bluetooth settings.
Item
Description
Default
Status
Use this menu to check the Bluetooth status.
N/A
Local Name
This item is used to set the local name for Bluetooth.
RF-BHS
Ping Code
This item is used to set the local ping code for
Bluetooth.
0000
Menu Interface Wi-Fi
Status
Config
SSID
Security
Password
Menu Interface Bluetooth
Status
Local Name
Ping Code

TSC MB240 Series Specifications

General

Print Method	Thermal Transfer/Direct Thermal
Resolution	203 dpi
Processor	32-bit RISC CPU
Operating Humidity	25-85% non-condensing
Connectivity	USB 2.0, RS-232
Media Sensor	Reflective, Transmissive
Media Type	Continuous, Die-cut, Black mark, Fan-fold, Notched
Media Width	25.4 mm
Media Thickness	0.06 mm
Media Core Diameter	25.4 mm (1")
Media Max Roll Diameter	127 mm (5")
Ribbon Width	110 mm
Ribbon Length	300 m
Ribbon Core Diameter	25.4 mm (1 inch)
Power	100 - 240 VAC, 50/60 Hz
Maximum Print Length	9999 mm
Label Width	25.4 mm
Label Thickness	0.06 mm
Power Supply	100-240V AC, 50-60Hz
Operating Temperature	5°C - 40°C
Storage Temperature	-20°C - 60°C
Certifications	CE
