- 42 -
This item is used to fine tune media stop location. Available
setting value range is from -120~120 dots.
This item is used to set the print mode. There are 3 modes as
below,
Next label top of form is aligned to the print
head burn line location.
Enable the label peel off mode.
Enable the label cutter mode
Enable the label rewind mode
This item is used to set print width. The available value range
is 2 ~ 999 dots.
This feature is used to print current printer available fonts list
to the label. The fonts stored in the printer’s DRAM, Flash or
optional memory card.
This feature is used to print current printer available images
list to the label. The images stored in the printer’s DRAM,
Flash or optional memory card.
This feature is used to print current printer available formats
list to the label. The formats stored in the printer’s DRAM,
Flash or optional memory card.
This feature is used to print current printer configuration to the
label.
This feature is used to set control prefix character.
This feature is used to set format prefix character.
This feature is used to set delimiter character.
This option is used to set the action of the media when you
turn on the printer.
Printer will advance one label
Printer will calibration the sensor levels,
determine length and feed label
Printer determine length and feed label
Printer will not move media
This option is used to set the action of the media when you
close the print head.
Printer will advance one label
Printer will calibration the sensor levels,
determine length and feed label
Printer determine length and feed label
Printer will not move media
This option is used to adjust print position vertically on the
label. The range is -120 to +120 dots.
This option is used to adjust print position horizontally on the
label. The range is -9999 to +9999 dots.
When reprint mode is enabled, you can reprint the last label
printer by pressing button on printer’s control panel.
