TSC MH340

5
1.1.3 Label Print Module Features (Optional)
The label print module offers the following features.
Print module
Resolution
8 dots/mm (203 dpi)
12 dots/mm (300 dpi)
24 dots/mm (600 dpi)
Max. print speed
356 mm (14”)/second
305 mm (12”)/second
152 mm (6”)/second
Max. print width
104 mm (4.09”)
Physical dimension
262.0 mm (W) x 227.0 mm (L) x 284.0 mm (H)
(10.31” (W) x 8.94” (L) x 11.18” (H))
Weight
4.2 kg (9.26 lbs)
Platform
Memory
512MB Flash memory, 256MB SDRAM
Interface
USB2.0, RS-232, Internal Ethernet 10/100 Mbps
Real time clock
Standard
Buzzer
Standard
Power supply
Input
AC 100-240V, 2A, 50-60Hz
Output
Total 243W
Supported media
Media type
Continuous, die-cut, black mark, fan-fold, notch, care label
Media wound type
Outside wound
Media width
20~114 mm (0.79" ~ 4.5")
Min. media length
5mm (0.2”)
Media thickness
0.06mm ~ 0.28 mm (2.36 ~ 11 mil)
Support ribbon
Ribbon type
wax, wax-resin, resin
Wound type
Outside wound, inside wound
Ribbon width
25.4 mm ~ 114.3 mm (1” ~ 4.5”)
Ribbon capacity
600 m long, max. OD 90 mm, 1” core
Accessory
 GPIO interface (DB15F)
 Peel off kit
 Regular guillotine cutter / Rotary heavy cutter / Care lable cutter
