TSC MH340 User Manual

64
8. Maintenance
This session presents the clean tools and methods to maintain the printer.
 For Cleaning
Depending on the media used, the printer may accumulate residues (media dust, adhesives, etc.) as a by-product of normal
printing. To maintain the best printing quality, you should remove these residues by cleaning the printer periodically. Regularly
clean the print head and supply sensors once change a new media to keep the printer at the optimized performance and extend
printer life.
 For Disinfecting
Sanitize your printer to protect yourself and others and can help prevent the spread of viruses.
 Important
- Set the printer power switch to O (Off) prior to performing any cleaning or disinfecting tasks. Leave the power cord
connected to keep the printer grounded and to reduce the risk of electrostatic damage.
- Do not wear rings or other metallic objects while cleaning any interior area of the printer.
- Use only the cleaning agents recommended in this document. Use of other agents may damage the printer and void its
warranty.
- Do not spray or drip liquid cleaning solutions directly into the printer. Apply the solution on a clean lint-free cloth and then
apply the dampened cloth to the printer.
- Do not use canned air in the interior of the printer as it can blow dust and debris onto sensors and other critical
components.
- Only use a vacuum cleaner with a nozzle and hose that are conductive and grounded to drain off static build up.
- All reference in these procedures for use of isopropyl alcohol requires that a 99% or greater isopropyl alcohol content be
used to reduce the risk of moisture corrosion to the printhead.
- Do not touch printhead by hand. If you touch it careless, please use 99% Isopropyl alcohol to clean it.
- Always taking personal precaution when using any cleaning agent.

TSC MH340 Specifications

General

Print technology	Direct thermal / Thermal transfer
Maximum resolution	300 x 300 DPI
Maximum printing width	104 mm
Display type	LCD
Product color	Black
Built-in display	Yes
Display resolution	320 x 240 pixels
Maximum media length	11430 mm
Maximum roll diameter	203.2 mm
Supported paper width	20 - 114 mm
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	25 - 85 %
Wi-Fi	-
Serial interface type	RS-232
Connectivity technology	Wired & Wireless
Ethernet LAN data rates	10, 100 Mbit/s
Flash memory	512 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	1D, 2D, AZTECCODE, Code 11, Code 128 (A/B/C), Code 39, Code 49, Code 93, Code-128 Codabar Library, Data Matrix, EAN128, EAN13, EAN8, GS1 DataBar, Interleaved 2/5, MaxiCode, MicroPDF417, PDF417, QR Code, UPC-A, UPC-E
Compatible memory cards	MicroSD (TransFlash)
Page description languages	TSPL-EZ

Weight and Dimensions

Depth	502 mm
Width	276 mm
Height	326 mm
