TSC MH340 User Manual

65
Cleaning Tools
 Cotton swab
 Lint-free cloth
 Brush with soft non-metallic bristles
 Vacuum cleaner
 75% Ethanol (for disinfecting)
 99% Isopropyl alcohol (for printhead and platen roller cleaning)
 Genuine printhead cleaning pen
 Mild detergent (without chlorine)
Cleaning Process:
Printer Part
Method
Interval
Print Head
I. Always turn off the printer before cleaning the printhead.
II. Allow the printhead to cool for at least one minute.
III. Use a cotton swab and 99% Isopropyl Alcohol or genuine print head cleaning pen to
clean the print head surface.
Clean the print head when
changing a new label roll.
Platen Roller
I. Turn off the printer.
II. Rotate the platen roller and wipe it thoroughly with the lint-free 99% Isopropyl Alcohol.
Clean the platen roller
when changing a new
label roll
Peel Bar
Use the lint-free cloth with 99% Isopropyl Alcohol to wipe it.
As needed
Sensor
Use brush with soft non-metallic bristles or a vacuum cleaner, to remove paper dust.
Clean upper and lower media sensors to ensure reliable Top of Form and Paper Out sensing.
Monthly
Exterior
Clean the exterior surfaces with a clean, lint-free cloth (water-dampened cloth). If necessary,
use a mild detergent or desktop cleaning solution then use the 75% Ethanol to wipe it.
As needed
Interior
Clean the interior of the printer by removing any dirt and lint with a vacuum cleaner, as
described above, or use a brush with soft non-metallic bristles then use the 75% Ethanol to
wipe it.
As needed

TSC MH340 Specifications

General

Print technology	Direct thermal / Thermal transfer
Maximum resolution	300 x 300 DPI
Maximum printing width	104 mm
Display type	LCD
Product color	Black
Built-in display	Yes
Display resolution	320 x 240 pixels
Maximum media length	11430 mm
Maximum roll diameter	203.2 mm
Supported paper width	20 - 114 mm
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	25 - 85 %
Wi-Fi	-
Serial interface type	RS-232
Connectivity technology	Wired & Wireless
Ethernet LAN data rates	10, 100 Mbit/s
Flash memory	512 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	1D, 2D, AZTECCODE, Code 11, Code 128 (A/B/C), Code 39, Code 49, Code 93, Code-128 Codabar Library, Data Matrix, EAN128, EAN13, EAN8, GS1 DataBar, Interleaved 2/5, MaxiCode, MicroPDF417, PDF417, QR Code, UPC-A, UPC-E
Compatible memory cards	MicroSD (TransFlash)
Page description languages	TSPL-EZ

Weight and Dimensions

Depth	502 mm
Width	276 mm
Height	326 mm
