TSC Printronix MB240T User Manual

38
◼ After clicking Set button, it'll pop-up the window tip
as below shown.
◼ IP address will be shown in the “IP address” field
and the Wi-Fi logo and IP address will be displayed
on the LCD control panel.
Note:
IP address should be shown within about 5 to 15
seconds after printer turn on. If not, please refer to
steps below to initialize the printer Wi-Fi module
settings then to setup it again.
◼ Remove the cable between the computer and the
printer.
◼ Go to main page, click Add Printer to add the
printer via Network.
◼ Select the printer and enter the setting page by
double clicking the printer.
◼ Click the Print Test Page button to print the test
page via Wi-Fi interface.

TSC Printronix MB240T Specifications

General

Type	Industrial Barcode Printer
Print Method	Thermal Transfer/Direct Thermal
Resolution	203 dpi
Max. Print Speed	6 ips
Max. Print Width	4.09" (104 mm)
Media Type	Label, Tag, Ticket
Media Core Diameter	1" (25.4 mm)
Ribbon Core Diameter	1 inch
Interface	USB, Serial, Ethernet
Power	100-240 VAC, 50/60 Hz
Supported Barcodes	Code 39, Code 128, UPC-A, UPC-E, EAN-8, EAN-13, Interleaved 2 of 5, Codabar, POSTNET, PDF417, QR Code, Data Matrix, MaxiCode
Operating Temperature	41°F to 104°F (5°C to 40°C)
