2.2.2 Interior View
1. Ribbon rewind spindle
2. Print head pressure position adjustment knob
3. Print head release lever
4. Ribbon supply spindle
5. Label roll guard
6. Label supply spindle
7. External label entrance chute
8. Damper
9. Print head
10. Platen roller
11. Label guide
12. Black mark sensor (shown as↓)
13. Gap sensor (shown as ▽)
9
10
11
7
5
1
2
3
4
6
8
13
12
