TSC TC310 Series User Manual

TC200/ TC300/ TC210/ TC310
Bar Code Printer Service Manual
23
3.8 Replacing the Gap Sensor (Transmitter)
1. Refer to section 3.2 to remove
the main board.
2. Remove 2 screws to release
the black mylar.
3. Remove 1 screw on the sensor
fixing plate to replace the
sensor PCB.
4. Reassemble the parts in the
reverse procedure.
