5.
Close the print head
m
echanism as
indicated.
6.
Close the printer cov
er. Use the
“
Diagnostic Tool
”
to set the printe
r
for cutter mode
by selecti
ng
“CUTTER” option
f
or Post
-Prin
t
Action settin
g then click “S
et”
button to enable t
he cutter mode.
Press the FEED bu
t
ton to tes
t
.
Note:
Please calibrate the g
ap/black m
ark sensor w
hen changing media.
