3.2 Loading the Ribbon
1. Open the printer top cover by
pressing the top cover open tabs
located on each side of the printer.
2. Insert the paper core to the ribbon
rewind spindle.
Note: Please follow the direction
when installing the ribbon rewind
spindle.
3. Insert the right side of ribbon rewind
spindle first. Then, insert the left side
to the hole at the left side of ribbon
rewind hub (green).
Note:
It can also be substituted by 0.5
or 1 inch paper roll with notches
on both sides. Please insert it at
the ribbon rewind hub directly.
To Next Page
