TSC AUTO ID Technology Co., Ltd. 65 Copyright 2009 All Rights Reserved.
*00abcde0000j = abcdej where j = 5-9
Note: 200 DPI: 1 mm = 8 dots
300 DPI: 1 mm = 12 dots
Recommended max. height of reversed black area is 12mm at 4” width. Height of
reversed area that is larger than 12 mm may damage the power supply and affect the
print quality.
Max. print ratio is different for each printer model. Desktop and industrial printer
print ratio is limited to 20% and 30% respectively.
Example
SIZE 100 mm,100 mm
GAP 0,0
CLS
RSS 300,300,"RSS14",0,2,2,"1234567890|ABCDEFG"
RSS 300,300,"RSS14T",90,2,2,"1234567890|ABCDEFG"
RSS 300,300,"RSS14S",180,2,2,"1234567890|ABCDEFG"
RSS 300,300,"RSS14SO",270,2,2,"1234567890|ABCDEFG"
PRINT 1,1
SIZE 100 mm,100 mm
GAP 0,0
CLS
RSS 300,300,"RSSLIM",0,2,2,"1234567890|ABCDEFG"
RSS 300,300,"RSSEXP",90,2,2,22,"1234567890|ABCDEFG"
RSS 300,300,"UPCA",180,2,2,"1234567890|ABCDEFG"
RSS 300,300,"UPCE",270,2,2,"000|ABCDEFG"
PRINT 1,1
SIZE 100 mm,100 mm
GAP 0,0
CLS
RSS 300,300,"EAN13",0,2,2,"123456789012|ABCDEFG"
RSS 300,300,"EAN8",90,2,2,"1234567|ABCDEFG"
RSS 300,300,"UCC128CCA",180,2,2,25,"1234567890|ABCDEFG"
RSS 300,300,"UCC128CCC",270,2,2,25,"1234567890|ABCDEFG"
PRINT 1,1
*Example of UPCE mode
SIZE 4,1
CLS
REM UPCE Rule 1: 00abc0000hij = abhijc, where c = 0-2
RSS 10,10,"UPCE",0,2,2,"001200000456|ABCDEFG"
RSS 210,10,"UPCE",0,2,2,"001210000456|ABCDEFG"
