2-1
CHAPTER 2
Unpacking the
Atomizer
This chapter contains a packing list and gives unpacking
instructions for the Model 3076 Constant Output Atomizer.
Packing List
Table 2-1 shows the packing list for the Model 3076 Constant
Output Atomizer.
Table 2-1
Model 3076 Atomizer Packing List
Qty Description Part No.
1 Model 3076 Constant Output Atomizer 307601
1 Model 3076 Accessory Kit 1030833
with the following parts
1 Instruction manual 1933076
1 5 ft Teflon
®
tubing 14 ga 3929552
2 O-ring 1-010 2501010
1 Fitting—SS plug, ¼ TU 1601563
1 Fitting—SS elbow,
1
⁄16 NPT 1601642
1 Fitting—SS conn, ¼ TU—
1
⁄16 MPT 1601643
1 Fitting—SS port conn ½ in. 1602153
10 ft Poly-Flo
®
tubing, ¼ in. O.D. 3929436
4 ft Conductive tubing, 0.44 in. I.D. 3001905
®Poly-Flo is a product of Imperial Eastman™
®Teflon is a registered trademark of E.I. du Pont de Nemours and Company
Note: The extra bottle or syringe pump required for nonrecirculation mode is not
included.
Unpacking Instructions
The Model 3076 Constant Output Atomizer is shipped with
protective coverings on the inlets and outlets. If anything is missing
or appears to be damaged, contact your TSI representative or
contact TSI Customer Service at 1-800-861-7919 (USA) or
(651) 490-3838. Chapter 6, “Atomizer Maintenance and Service,”
gives instructions for returning the Atomizer to TSI.
