5-2 Model 3076 Constant Output Atomizer
Salt Particle Size vs. Solution Concentration
1
10
100
0.000001 0.00001 0.0001 0.001
Salt Concentration (g/cc)
Particle Diameter (nm)
Geometric Mean
Mode
Geo. Standard Deviation
Figure 5-1
Particle Diameter Mean, Mode and Standard Deviation vs. Salt Concentration
(grams of NaCl per cm
3
of H
2
O)
Size Distribution of NaCl Aerosols
0.0E+00
5.0E+05
1.0E+06
1.5E+06
2.0E+06
2.5E+06
3.0E+06
3.5E+06
10 100 1000
Particle Diameter (nm)
Particle Number Concentration (#/cc)
0.00012 g/cc
0.000012 g/cc
0.000001 g/cc
Figure 5-2
Size Distribution of Sodium Chloride Aerosols Generated by the Atomizer
