A-1
APPENDIX A
Specifications
The following specifications, which are subject to change, describe
the most important data of the major components.
Table A-1
Specifications of the Model 3076 Constant Output Atomizer
Number mean droplet diameter . 0.30 µm DOP; 0.35 µm water
Max PSL size ............................ 2 µm
Geometric standard deviation .... 1.6 to 2.0
Particle material ....................... PSL, DOP, oils, and other aqueous or
alcohol solutions or suspensions
Generation rate (nominal) .......... 2
× 10
6
particles/cm
3
(10
8
particles/sec)
Air flow rate............................... 3.0–3.5 L/min at 2.5 kg/cm
2
[35 psig]
Liquid flow rate ......................... 20 cm
3
/min at 35 psig
0.59 cm
3
/min nominal with syringe
pump”
Liquid consumption rate (water).. Approximately 0.1 cm
3
/min
Dimensions
Base (L x W) ........................ 20 × 30 cm [7.9 × 11.8 in.]
Stem (L x W x H) ................. 6 × 8 × 46 cm [2.4 × 3.1 × 18.1 in.]
Weight....................................... 4.5 kg [10 lb]
