16 Chapter 3
DISPLAY SETUP
Display Setup menu is where you will setup the desired parameters to
be displayed on the instrument screen. With a parameter highlighted
you can then use the ON soft key to have it show up on the instrument
screen or select the OFF soft key to turn off the parameter. Use
PRIMARY soft key to have a parameter show up on the instrument
screen in a larger display. A total of 5 parameters can be shown on
the display, 1 primary (large font) and 4 secondary. Parameters
shown in the Display Setup screen are dependent on the type of
probe currently connected.
When set to PRIMARY, measurement will be the large font on the
display.
When set to ON, measurement will be displayed as a secondary
parameter (up to 4 can be displayed).
When set to OFF, measurement will not be displayed.
Pitot Velocity and AFProbe Velocity cannot both be ON at the
same time, nor can one be set to PRIMARY and the other to ON.
Only one can be ON at any given time.
MENU
Zero Press
Display Setup
Settings
Flow Setup
VOC Setup
Actual/Std Setup
Data Logging
Zero CO
Applications
Calibration
Bluetooth Functions
DISPLAY SETUP
Velocity *ON
Flow OFF
Pitot Velocity OFF
Pressure ON
Temperature ON
Baro Press OFF
ON PRIMARY OFF
