18 Chapter 3
ACTUAL/STANDARD SETUP
Choose Actual/Standard measurements and parameters in the Act/Std
Setup menu. The Model 9565 measures the actual barometric
pressure using an internal sensor. The temperature source can be
entered manually or taken from a probe that measures temperature
(plug in probe or thermocouple). The Entered Temp range is from -40
to 1832°F (-40 to 1000°C).
For more information on Actual and Standard conditions, refer to
Application Note TSI-109.
MENU
Zero Press
Display Setup
Settings
Flow Setup
VOC Setup
Actual/Std Setup
Data Logging
Zero CO
Applications
Calibration
Bluetooth Functions
ACTUAL/STD SETUP
Setting Standard
Temp source Entered
SETTING
Standard
Actual
TEMP SOURCE
Entered Temp 70F
Probe
Thermocouple 1
Thermocouple 2
