Part Two
4. Press the NORMAL key to select LAL (low alarm menu item). The current
value will be displayed.
5. Press the arrow keys ▲/▼ to change the item value to 60.
6. Press the NORMAL key to save the value and to exit to the menu. LAL will
be displayed.
Note: The monitor will flash SAVE and beep which indicates data has been
correctly saved.
7. Press the ▼ arrow until End is displayed.
8. Press the ▼ key once to exit the menu.
Menu and Menu Items
The EverWatch monitor has two menus: a configuration (CONF) menu and a calibration
(CAL) menu. All the software programming takes place inside of these two menus. The
configuration menu allows you to tailor the unit to your specific application. The
calibration menu is only used when calibration is required. Changing any item is
accomplished by using the keypad, or if communications are installed through the RS-
485 Communications port. If you are unfamiliar with the keystroke procedure please see
“Software Programming” for a detailed explanation. This section provides the following
information:
Complete list of menu and all menu items
Gives the menu or programming name
Defines each menu items’ function: what it does, how it does it, etc.
Gives the range of values that can be programmed.
Gives default item value (how it shipped from factory).
Figure 3 shows a chart of all the Model 8610 standard monitor menu items.
CALIBRATION
Calibration zero (LCAL)
Calibration Span (HCAL)
Access Code (PASS)
Calibration End (End)
CONFIGURATION
Low Alarm (L_AL)
High Alarm (H_AL)
Display Filtering Period (dSPL)
Alarm Reset (ALr)
Alarm Disable (dSbL)
Analog Output (AOUt)
RS-485 Type (PrOt)
RS-485 Address (Addr)
Access Code (PASS)
Configuration End (End)
Figure 3: Menu Items - Model 8610 Standard Monitor
