Instrument Operation 5-23
Check the checkbox to enable. When enabled, the
SMPS spectrometer will accept start and stop triggers
through the digital I/O port on the back of the
classifier. See the Communication Ports section in
Chapter 4 for details on how to configure an external
trigger.
Use the alphanumeric on-screen keyboard to
associate a note with subsequent scans (254
character limit). The note will be attached to all
subsequent scans and can be viewed on this screen
or in the exported data.
Notes: The Notes field is cleared at power-down.
If the notes field already has entries, make sure the Shift key is
deselected to edit a portion of the note.
A carriage return in the Notes field is represented as back-to-
back pipe symbols || in exported data files.
