2-34 Electrostatic Classifier Model 3082 and SMPS Spectrometer Model 3938
To install the flow equalizer assembly, follow these instructions:
1. Remove the flow equalizer
assembly from the SMPS
Accessory Kit.
2. Push the flow equalizer assembly
onto the Monodisperse Flow
port on the DMA. Tighten finger-
tight, then use wrench to tighten
an additional ¼ turn.
C a u t i o n
Nylon ferrules are provided with the flow equalizer assembly. Do NOT
replace the nylon ferrules with metal ferrules as this may result in
permanent swaging of the flow equalizer assembly.
