TSL Tallyman TM1 User Manual

TallyMan V1.81 on
|
I
nstallation
24
Parallel Tally connectors
Parallel (GPI) tallies are connected directly to the Tally 1, 2, 3 & 4 D37 connectors on the TM2+
controller.
Tally inputs
To activate a tally input, pull the relevant pin to ground or 0V. The common or ground connection is
connected to pin 36.
TALLY 1 INPUT CONNECTORS
D37 SOCKET
1
TALLY 1
20
TALLY 20
2
TALLY 2
21
TALLY 21
3
TALLY 3
22
TALLY 22
4
TALLY 4
23
TALLY 23
5
TALLY 5
24
TALLY 24
6
TALLY 6
25
TALLY 25
7
TALLY 7
26
TALLY 26
8
TALLY 8
27
TALLY 27
9
TALLY 9
28
TALLY 28
10
TALLY 10
29
TALLY 29
11
TALLY 11
30
TALLY 30
12
TALLY 12
31
TALLY 31
13
TALLY 13
32
TALLY 32
14
TALLY 14
33
0v
15
TALLY 15
34
+12 / +24V see note
16
TALLY 16
35
Ext Voltage Ref Pin
17
TALLY 17
36
0v
18
TALLY 18
37
-
19
TALLY 19
