Tsonic TUF-2000 Series User Manual

>> Ultrasonic Flow meter User Manual
24
M-5
20mA calibration for AI4 input
M-6
4mA calibration for AI5 input
M-7
20mA calibration for AI5 input
M-8
Lower Temperature Zero setup for the PT100
M-9
Higher Temperature Zero setup for the PT100
M-A
Temperature Calibration at 50℃
M-B
Temperature Calibration at 84.5℃
6.4 Quick setup of measured parameters
Accurate measured parameters can have a great influence on measuring precision and reliability. It
is suggested to measure the practical perimeter and wall thickness of the pipeline. Ultrasonic
thickness gauge can be used to measure the pipe thickness.
Measured parameters setup is from Menu10 to Menu29. Please complete one by one.
>>> Following parameters need to be inputted before measurement:
1. Outer diameter unit: mm
2. Pipe thickness unit: mm
3. Pipe material
4. Lining parameters: thickness and sound velocity (If have lining)
5. Liquid type
6. transducer type
7. transducer mounting type
>> Above parameters setup generally follow the steps below:
1.Press keys MENU 1 1 to enter M11 window to input the pipe outer diameter, and then press
ENT key.
2.Press key ▼/- to enter M12 window to input the pipe outer diameter and then press ENT key.
3.Press key ▼/- to enter M14 window, and press ENT key to enter the option selection mode.
Use keys ▲/+ and ▼/- to select the pipe material, and then press ENT key.
4.Press key ▼/- to enter M16 window, press ENT key to enter the option selection mode. Use
keys ▲/+ and ▼/- to select the liner material, and then press ENT key. Select “No Liner”,
if there is no liner.
5.Press key ▼/- to enter M20 window, press ENT key to enter the option selection mode. Use
keys ▲/+ and ▼/- to select the proper liquid, and then press ENT key.
6.Press key ▼/- to enter M23 window, press ENT key to enter the option selection mode. Use
keys ▲/+ and ▼/- to select the proper transducer type, and then press ENT key.
7.Press key ▼/- to enter M24 window, press ENT key to enter the option selection mode. Use
keys ▲/+ and▼/- to select the proper transducer mounting method, and then press ENT key.
8.Press key ▼/- to enter M25 window and get the transducer installation distance.
9.Press MENU 2 6 to store the parameters setup.
