4. CONSTRUCTION
1. Stand
2. Clamps
3. Control ring
4. Rack-and-pinion lift
5. Rotary mechanism frame
6. Rotary mechanism frame
7. Abrasive holder stroke limiters
8. Hinge unit
9. Lifting mechanism knobs
10. Body
11. Coupling
12. Abrasive holder
13. Digital integrated angle nder
(g. 1)
1
2
3
4
5
6 7 11 12 13
8
9
10
