6. SPECIFICATION OF INPUTS AND OUTPUTS
6.11.4 Maximum ratings
Symbol Parameter Min Max Unit
V
CAN_CN
Bus voltage under overload conditions
(short circuit to supply voltages)
-58 58 V
6.11.5 Characteristics
Symbol Parameter Note Min Max Unit
C
out
Pin output capacitance 100 pF
V
in-CMM
Input common mode range 1 -12 12 V
V
in-dif
Differential input threshold voltage 0.5 0.9 V
(V
CAN_CNH
− V
CAN_CNL
)
V
out-dif
Differential output voltage dominant state 1.5 3.0 V
(V
CAN_CNH
− V
CAN_CNL
)
V
out-dif
Differential output voltage recessive state -0.1 +0.1 V
(V
CAN_CNH
− V
CAN_CNL
)
V
CAN_CNL
,
V
CAN_CNH
Common mode idle voltage (recessive state) 2 3 V
I
CAN_CNL
Output current limit -40 -100 mA
I
CAN_CNH
Output current limit 40 100 mA
S
Tr
Bit rate 2,3 25 1000 kbit/s
Note 1 Due to possible high currents in the wiring harness the individual ground potential of
control units may differ up to several volts. This difference will also appear between
a transmitting and receiving control unit as common mode voltage and does not in-
fluence the differential bus signal if the common mode voltage is within the common
mode limits.
Note 2 The arbitration process will allow 1 Mbit/s operation only in small networks and re-
duced wire length. As example a so-called private CAN, a short point-to-point con-
nection (less than 10 m) between only two nodes can be operated at 1 Mbit/s.
Note 3 For typical network size and topology (network with stub wires) and more than two
nodes the practical limit is 500 kbit/s.
