6. SPECIFICATION OF INPUTS AND OUTPUTS
6.13 Camera supply
6.13.1 Pinout
Connector Pin no. Note Function
C1 9 Camera 1 Supply
C1 17 Camera 1 GND
C1 7 Camera 2 Supply
C1 15 Camera 2 GND
C1 28 1 Camera 3 Supply
C1 23 1 Camera 3 GND
C1 20 1 Camera 4 Supply
C1 19 1 Camera 4 GND
Note 1 Only for Vision 312Plus products.
6.13.2 Functional description
A 12 V supply is provided to power external cameras.
6.13.3 Maximum ratings
Symbol Parameter Min Max Unit
V
sc
Short circuit voltage range -1 33 V
6.13.4 Characteristics
Symbol Parameter Note Min Max Unit
V
cam
Output voltage 1 0 0 V
V
cam
Output voltage 2 V
BAT+
-1.7 0.9*V
BAT+
V
V
cam
Output voltage 3 11.7 12.5 V
I
out
Overall output current 4 1500 mA
I
out
Overall output current 5 2500 mA
Note 1 V
BAT+
< 7.5 V (for power supply below 7.5 V, see section 6.1.2.1.)
Note 2 7.5 V V
BAT+
13.3 V
Note 3 V
BAT+
> 13.3 V
Note 4 For Vision 312
Note 5 For Vision 312Plus
