10. CONNECTORS AND CABLE SPECIFICATIONS
10.5 Cables
TTControl recommends the following cables for mating connectors:
Connector Function Article description Type
designation
Recommendation
C1 CAN Single twisted pair,
120 Ω, 2x0.35 mm
2
FLRY 2x35-A
H=20 GE/GR
Automotive standard
C1 Video
signals
Shielded video
cable (Coax type,
75 Ω impedance,
signal cable)
Lapp 2170010,
Helu 40010,
Medi 2270187
C1 all other
functions
0.75 mm
2
0.75 mm
2
Automotive standard
A 100BASE-T1
100BASE-TX
unshielded twisted pair
(-T1 with one pair)
(-TX with two pairs)
4x0.14
Cu SF/TQ.
RosenbergerHSD
LD5-105-xxxx-A-x
B, D USB OTG
USB Host
Standard USB cable 4x0.14
Cu SF/TQ
RosenbergerHSD
LD5-105-xxxx-F-x
C reserved for
future use
